FiberHome AN5116-06B Product Description

5 Technical Specification and Standard
Table 5-16 Ethernet Optical Interface Specifications of the HU4A Card (Continued)
Item 10000Base-SR
Minimum transmitting optical power
-6 dBm
Minimum overload optical power
0
Maximum receiving sensitivity
-11 dBm
Minimum extinction ratio 3 dB
5.2.6 Interface Specifications of the GU6F / GU6B / GSOF
Card
Table 5-17 Specifications of Ethernet Optical Interfaces on the GU6F / GU6B / GSOF Card
Item 1000Base-SX 1000Base-LX
Interface Type
LC/PC LC/PC
Interface rate 1000 Mbit/s 1000 Mbit/s
Applicable standard
IEEE 802.3z IEEE 802.3z
Central wavelength
850 nm 1310 nm
Maximum transmission
distance
500m 20km
Maximum transmitting optical
power
-4 dBm -3 dBm
Minimum transmitting optical
power
-9.5 dBm -11.5 dBm
Minimum overload optical
power
0 -3 dBm
Maximum receiving sensitivity
-17 dBm -19 dBm
Minimum extinction ratio 9 dB 9 dB
Table 5-18 Specifications of Ethernet Electrical Interfaces on the GU6F / GU6B / GSOF Card
Item 10/100/1000Base-T
Interface Type
RJ-45
Interface rate
Auto-negotiated to 10 / 100 / 1000 Mbit/s
Transmission media CAT-5
Applicable standard
IEEE 802.3-2005
Transmission distance 100m
Version: A/1 5-11
