AN5116-06B/AN5516-06/AN5516-04 Optical Line Terminal Equipment Hardware Description
Table 3-38 Indicator LEDs (Continued)
Identifier
Meaning
Color Status
Description
OFF
The card is working normally.
LINK1 to 8
Port status
indicator
LED
Green
ON
The port is connected to an ONU at the far end, and
the ONU has been authorized.
OFF
The port is not connected to an ONU at the far end,
or the far-end ONU is not authorized.
Technical Specifications
Item
Specification
Network standards
IEEE 802.3, IEEE802.3x, IEEE 802.3ah, IEEE 802.3av, IEEE
802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3ah-2004,
IETF RFC2236, etc.
Switching mode
Store-and-forward
Supported MAC address
quantity
32 k
Maximum split ratio
1:128
Maximum LLID 1024
Bandwidth allocation
granularity
64 kbit/s
Optical fiber connector
SC/PC
Network cable
G.652 single-mode fiber
Matching Module
Item
Specification
10G EPON optical module
10/1.25G-20km-10G EPON OLT asymmetric - XFP (10G/1G
BASE-PRX30)
10/1.25G-20km-10G EPON OLT symmetric-XFP (10G BASE-
PR30)
Note 1: 10G EPON Optical Module shows the module specifications.
Function
See Function Overview of the EPON / 10G EPON Service Card.
