HG6145F GPON Optical Network Terminal Product Manual
Table 2-2 Service Types Supported by the HG6145F
ONT Type
Internet Service Multicast Service Voice Service Wi-Fi Service
HG6145F
√ √ √ √
Note: “√”indicates “supported”; “×” indicates “not supported”.
Service Reliability
The HG6145F supports MTBF up to 30 000 hours.
2.32.3 Interface Specifications
2.3.12.3.1 GPON Interface
Table 2-3 GPON Interface Specifications
Parameter
Specification
Standard compliance
ITU-T G.984, Class B+
Transmission rate
Rx: 2.5 Gbit/s; Tx: 1.25 Gbit/s
Interface mode
Single-mode
Interface type
SC/UPC
Maximum transmission distance 20 km
Central wavelength
Tx: 1310 nm; Rx: 1490 nm
Optical power
Tx optical power: 0.5 dBm to 5.0 dBm
Rx optical power: -8 dBm to -29 dBm
Extinction ratio More than 10 dB
Receiving sensitivity
-27 dBm to -29 dBm
Maximum overload optical power
-8 dBm
2.3.22.3.2 LAN Interface
Table 2-4 LAN Interface Specifications
Parameter
Specification
Standard compliance
IEEE 802.3ab
Interface type
RJ-45
Interface rate
10 Mbit/s, 100 Mbit/s or 1000 Mbit/s
Maximum transmission distance 100 m
4
Version: A
