EXPLODED VIEW
1
Cover
10 Chassis 19
Controller
2
Fixed frame 11 Fan motor 20 Controller mounting board
3
Front panel 12 Compressor 21 Four way valve
4
Wire controller 13 Evaporator 22 Titanium heat exchanger
5
Copper tube 14 PCB 23 EEV
6
Motor bracket 15 Support column 24 Low pressure switch
7
Left side panel 16 Rear side panel 25 High pressure switch
8
Guide air circle 17 Pressure gauge 26 Copper tube
9
Fan blade 18 Cable fixing head 27 Maintenance panel
8
