Fidelis Network Series - Appliance Logical Network Configuration

QUICK START GUIDE
Fidelis Network™ High Capacity Collector
www.fidelissecurity.com ©Fidelis Cybersecurity
5
DB Network
The DB Network allows communication between Collector Controller and Controller XA nodes. This
network must be independent from other networks. IPv4 addressing only.
Appliance
Switch Port Type
Qty.
Collector Controller 10G
10GbE Fiber SR, LC connector (may require SFP+ transceiver)
1
Collector XA4
10GbE Fiber SR, LC connector (may require SFP+ transceiver)
1
SYNC Network
The SYNC Network provides transport for database node synchronization. This network must be
independent from other networks. Only IPv4 addresses are supported.
Appliance
Switch Port Type
Qty.
Collector Controller 10G
n/a
Collector XA4
10GbE Fiber SR, LC connector (may require SFP+ transceiver)
1
ILO / IPMI Network
Optional network for remote/out-of-band server administration.
Appliance
Switch Port Type
Qty.
Collector Controller 10G
GbE - Copper Cat5 RJ45 port
1
Collector XA4
GbE - Copper Cat5 RJ45 port
1
5. Appliance — Logical Network Configuration
Each physical connection must be assigned logical network information. Build a table of the logical
information for each appliance (sample below) that you can reference during configuration. You will
refer to this table multiple times during setup. Appendix A has a worksheet you may use.
