1.1 INTRODUCTION
This disc ridger light duty is equipped with light-duty box frame specially designed
for deep ploughing / land preparation of rough soil.
1. TECHNICAL DATA
Compliance with the instructions in this handbook is also important since
Manufacturer declines all and every responsibility for damage to persons or
property caused by negligence and failure to comply with these instructions.
This handbook contains the use and maintenance instructions with a list of the
spare parts of the disc ridger light duty.
Regular and satisfactory operations together with economic and long lasting use of
the implement depend on the compliance with instructions given in this handbook.
1.2 WARRANTY
When the machine is delivered, check that it has not been subjected to damage
during transport and that the accessories are in a perfect condition and complete.
The purchaser may only make the claims under warranty when he has complied
with the warranty conditions in the supply contract.
1.3 WHEN THE WARRANTY BECOMES VOID
Any claims following the receipt of damaged goods shall be presented in writing
within 8 days from the receipt of the goods.
4. If the implement is used in very hard/stony soil no warranty of discs will be given.
5. If the implement is not lifted while taking a turn of the tractor. No warranty will be
given if the service and greasing is not done on time.
1.4 WARNING SIGNALS
1. Thoroughly read the instruction manual before proceeding with the various
operations.
3. When the user has failed to comply with the instructions in this handbook.
Besides the cases specified in the supply agreement, the warranty shall in any case
become void:
1. When the implement has been used beyond the specified power limit like
(tractor horse power).
2. When repairs made by the customer without authorization from the
manufacturer or owing to installation of spurious spare parts, the machine is
subjected to variations and the damage can be ascribed to these variations.
2. USAGE INSTRUCTIONS
3. Attach the left arm of the tractor to the disc ridger first.
2.1 BEFORE USE
2. Keep maintenance and warranty according to this handbook.
1. Place the disc ridger duly leveled on the flat piece of land.
• Before mounting of disc ridger light duty make sure that all nuts & bolts are
properly secured.
2.2 ATTACHING THE RIDGER TO THE TRACTOR
2. Reverse the tractor to the disc ridger ( Do not drag the disc ridger up the tractor).
1. The horsepower of tractor selected should match the implement.
2. Adjust the front and rear wheel track width.
5. All plough adjustment should be carried out.
3.2 ADJUSTMENT
Also determine soil and trash conditions of the field and make the preliminary
adjustments. e.g.
3. Provide adequate front end ballast for tractor stability.
Select load and depth control setting according to tractor operator's manual
5. Attach the lower right arm. If gap between the hole and mounting pin is too close
or too distant, turn the control arm in or pull it away to an appropriate distance.
You may have to adjust both height and distance at the same time. When the
hole in tractor arm and mounting pin are even, insert the pin in the hole and lock it
with the lynch pin.
The following are typical instructions for preparing a tractor for operation:
4. Attach the central arm to the disc ridger. To attach, turn the screws on both sides
to an equal length. If the arm is too short or too long, turn the screw to adjust both
at the same time.
6. After attaching the disc ridger, lift it and adjust the control arm parallel to the
ground. When you look from both rear or sideways, the discs should all be
touching the ground uniformly.
3. TRACTOR PREPARATION
3.1 INSTRUCTIONS FOR TRACTOR PREPARATION
4. Provide proper rear furrow wheel weight.
