6. FIGURES AND PART NO. DETAILS
PART NAME
FRONT FRAME ASS. (1-ROW)
HITCH PIN 20MM (HUB LENGTH)
LINCH PIN 10X43L
HEX HEAD BOLT M16X2PX5OL
REAR FRAME ASSEMBLY
FRONT LEVER FLAT
REAR LEVER FLAT
LEVER BUSH
HEX HEAD BOLT M16X2PX100L
SPRING WASHER M16
NULOCK NUT M16X2P
HEX BOLT M18X2.5PX65L
SPRING WASHER 18MM
NYLOCK NUT M18X2.5P
PIN Ø19X140MM
FRAME JOINT PLATE
HEX. HEAD BOLT M16X2PX125L
UPPER FLANGE (7.5")
LEG ASS. (LIGHT DUTY)
HEX. HEAD BOLT M20X2.5PX100L
SPRING WASHER M20
NYLOCK NUT M20X2P
HEX HEAD BOLT M16X2PX95L
SPINDLE ASSEMBLY
STAND PIPE ASSEMBLY
SPRING WASHER 25MM
NYLOCK NUT M25.4
SR. NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
PART NO.
76920001
10020013
10020022
10260078
76930001
76940002
76940003
10070029
10260068
10270005
10280005
10260315
10270006
10280020
10020120
76920007
10260072
76930006
76950001
10260087
10270016
10280021
10260126
72120001
72130001
10270007
10280008
QTY.
1
2
3
2
1
2
2
1
1
21
21
2
2
2
1
2
16
2
2
2
2
2
2
2
1
2
2
1 2 3 4 5 6 7 8 9
10
11
12 13 14 15
C.S.K. BOLT M12x40x2P
PLAIN DISC 26"x6MM
SPINDLE
SPRING WASHER12MM
PLAIN NUT M12x1.75P
OIL SEAL 150.5x140.5x18T
BEARING - 32213
GREASE NIPPLE 10x15x1.5P
BEARING HOUSING
BEARING - 32209
CASTEL NUT M36x2P
SPLIT PIN 4x65mm
GESKET
EARING HOUSING CAP
ALLEN BOLT M10x35x1.5P
Sr. No. DESCRIPTION PART NO.
QTY.
5 1 1 5 5 1 1 1 1 1 1 1 1 1 3
10260052 10240039 10380001 10270003 10280028 10010009 10050012 10300005 10090009 10050013 10280071 10020055 10040020
10180011
10260093
