Fiessler AKAS-IIM - Page 7

7
Indicator lights on Frontpanel and switches for safe operation
Doku Nr. 988 Stand 3.2.2016 / Aui
Fiessler Elektronik OHG - Kastellstrasse 9 - D 73734 Esslingen - Tel.: ++49 711/9196970
Lichtschranke Frei
Receiver Ricervitore
Typ: AKAS® LC
FIESSLER
E L E K T R O N I K
Upper plug: Spinotto superiore:
1R = 5v
2R = 2v
3R = 4v
4R = 7h
5R = 5h
= PE
4
5
1
2
3
Lower plug: Spinotto inferiore:
1L = 3h
2L = 4h
3L = 8h
4L = 6v
5L = 1v + 3v
6L = 6h  
4
5
1
2
3
6
Typ 4
EN 61496
IP 54
+24V mut. chanel 1
muting contact 1b
muting contact 2b
+24V box bending
output 2
PE
+24V DC
0V DC
+24V box b. acknowled.
+24V muting request chanel 2
muting contact 1a + 2a
output 1 
+24V muting canale 1
contatto muting 1 ( 1b )
contatto muting 2 ( 2b )
+24V Funzione Cassetto
Uscita 2
PE
+24V DC
0V DC
+24V Funzione Cassetto o.k.
+24V Segnale muting canale 2
contatto muting 1a + 2a
Uscita 1 
Max. Range: 6m Range massimo: 6m
AKAS®LC interrupted
AKAS®LC interrotto
E3
E4
Adjustment controls
Controllo Funzioni
E1
E2
Box bending function activated and E1 muted
Attivata Funzione Casetto e E1 bypasssto
Caution: Before connecting the plugs to power, please make sure that the headless screw at the mounting brackets make
contact with the yellow housing. If necessary please remove the yellow paint layer at this spot.
Attentione: All´nizio di ogni, la vite testa del support dovrebbe fare contatto con la custodia gialla del ricevitore. In caso di
bisogna, rasciare la tinta gialla dalla custodia.
AKAS® II LC
AKAS®LC free
AKAS®LC libero
U
L
R
LISTED
c
E4
E1
E2
Ausricht-
kontrollen
Fiessler Elektronik - Kastellstrasse 9 - D 73734 Esslingen - Tel.: 0711/9196970
Empfänger / Receiver
Typ: AKAS®-LC F





















SP
SGA
SGO
SGS


Kastenbiegen
box-bending
FIESSLER
E L E K T R O N I K
Typ 4
EN 61496
RXOK2
RXOK1
NLW
NA1
NA3
NA2
FUS
FUO
EDMO
EDMS
Adjustment
26
25
24
23
22
21
20
19
18
17
16
15
14
1
2
3
4
5
6
7
8
9
10
11
12
13
NLW 13
SGA 12
SP 11
SGO 10
SGS 9
FUO 8
FUS 7
+ Ub Transmitter 6
- Ub Transmitter 5
RS 232 GND 4
- Ub 0V 3
+ Ub 24VDC 2
Erde 1
26 RS 232 out
25 KAST
24 OSSD2
23 OSSD1
22 RXOK2
21 RXOK1
20 HUSP
19 S_EU2K
18 NA3
17 NA2
16 NA1
15 EDMO
14 EDMS
Steckerbelegung
Connections
Muting
OSSD1
OSSD2
OSSD1
OSSD2
off
on
DOK 982
1
2
3
4
5
1
2
3
4
5
6
6


























1
26
25
24
23
22
21
20
19
18
17
16
15
14
2
3
4
5
6
7
8
9
10
11
12
13
ajustment controll-Leds of the receiver elements E1, E2, E4
LEDs are on if the beam does focus at all (see page 26)
integrated mutinglamp
lamp is on if the protective field of the AKAS is not activated
lamp is flashing if EDM- or SP-input-signals are wrong
(see page 47)
LEDs for safety outputs (OSSDs, Fail-Safe PNP)
red LEDs are on if the OSSDs are in OFF status
green LEDs are on if the OSSDs are in ON status
LED is on if box bending funktion is activated
Indicator lights for in- and outputs
connection lid






















SP
SGA
SGO
SGS
RXOK2
RXOK1
NLW
NA1
NA3
NA2
FUS
FUO
EDMO
EDMS
Indicator lights for in- and outputs
(see page 47)
Outputs for
release of rear stoppers
Input for Overruntraverse controll
Inputs for control of protective grids or
doors and emergency-off circuits
Inputs for press start / stop
(release of closing stroke)
Input for stop contactor control
Input for safety point
Output for demand for slow speed
Input for position control in slow speed
5
view after removing the connection lid
on the receiver
view of the receiver elements
AKAS®-LCF
1.5
1
hex-switch 4
hex-switch 3
hex-switch 2
hex-switch 1
(see page 45,46)
connector plug
Pin 1
Pin 14
E2
E4
E1
bendingline
E3
