FIFOTRACK Q3 User Manual

Q3 USER GUIDE
8
4. Specification
Item
Specification
Dimension
65*46*17mm
Weight
48g
GSM Module
Quectel EG915U, Cat 1 type
GPS Chipset
ZKW AT6558R
Charging Voltage
DC 5V/1A
Internal Battery
1000mAh/3.7V Lithium-ion battery
Full charging time
<2 hours 10 minutes
Power Consumption
Average 2.4mA standby current
Working hours
Refer to chapter 5 for details. 5 minutes time interval working for 4 days
3 hours
Microphone
Built-in microphone
Speaker
Built-in speaker
Operating
Temperature
-20℃~70℃
Humidity
5%~95%
Waterproof
IP67 (Testing condition: Immersed in 20cm depth water for 30 minutes)
LED Light
2 LED lights indicate GPS/GSM/Power status
Button/Switch
1 SOS button, 1 power button, 1 call button
Flash Memory
4MB (Buffer storage: GPRS 8000 units, SMS 400 units)
Motion Sensor
3-axis motion sensor (Fall down/Movement detection)
Vibration motor
Built-in, vibration reminder incoming call/button press
WiFi
2.4 GHz 802.11b (Rx)
Bluetooth
BlueTooth Low Energy (BLE4.2 BR/EDR)
Frequency Band
EU version: for Asia, Europe,
Middle East, Africa, Australia
countries
2G GSM: B2/B3/B5/B8
4G FDD-LTE:
B1/B3//B5/B7/B8/B20/B28
LA version: for Latin America
countries
2G GSM: B2/B3/B5/B8
4G FDD-LTE:
B2/B3/B4/B5/B7/B8/B28/B66
USA and Canada
Don’t support
GPS Sensitivity
-167dBm
GPS Start Speed
Cold start 30s
Hot start 1s
Position Accuracy
2.5m
Charging Cradle
Available, standard packing accessory
Charging Port
1 magnetic contact port for Configuring/Upgrading/Debugging

FIFOTRACK Q3 Specifications

General

Brand	FIFOTRACK
Model	Q3
Category	GPS
Language	English
