FIFOTRACK S20 User Manual

S20 USER GUIDE
10
7 Specification
Item Specification
Dimension 80*53*21mm
Weight 157g
GSM Module SIMCOM800C
GPS Module
Quectel L70-R
Input Voltage
DC 8~92V/1.5A
Internal Battery
300mAh/3.7V
Power
Consumption
30-35mA standby current
Internal Battery Life
2.4 hours at 30 seconds time interval
3.6 hours at 600 seconds time interval
Operating
Temperature
-20
℃
~70
℃
Humidity
5%~95%
LED Light 3 LED lights indicating GPS/GSM/External power status
Button/ Switch 1 power switch (inside case)
Flash Memory 8MB (GPRS data 20400 units, SMS data 320 units)
Sensor 3D Acceleration Sensor
GSM Frequency
Band
GSM 850/900/1800/1900MHz
GPS Sensitivity -161dBm
GPS Start Speed Cold start 35s
Hot start 1s
Position Accuracy 10m
I/O Port 2 Digital inputs – input1 is smart input, can be configured to negative
or positive input, default is negative. Input2 is positive input for ACC.
1 Analog input, voltage range is 0-12V
1 Output
1 USB port (inside case)
8 First Use
8.1 Installing the SIM Card
 S20 is 2G tracker. Make sure the SIM card is compatible with 2G.
 SIM card is Micro type, 15*12mm.
