| TT10 IN-LINE TURBINE METER
INSTALLATION AND OPERATION MANUAL
Press Calibration/Fluid Type Factor (CAL)
The TT10 Series Meters provide 20 preset factors for different fluid types/viscosities.
Use of calibration factors is intended to provide the most accurate metering solution for a specific fluid. A CAL factor of 0 is for use with the thinnest
fluids and increases for higher viscosity fluids.
1. Press and hold button 3 for three seconds. The current dispensed count value will disappear and only the CAL icon and the current value
will be displayed.
2. Repeatedly pushing button 3 will increment the number up to 19, then return back to zero.
3. After the desired fluid factor has been selected, press button 2 to lock in the fluid factor and return the meter to normal operating mode.
Table 1: CAL Factor Table for Fluids at 70ºF / 21ºC
Fluid cSt Cal Fluid cSt Cal Fluid cSt Cal
Heptane 0.36 0 Kerosene 2.62 7 Ethylene Glycol 19.1 14
0.48 1 Diesel 3.48 8 2,4-D 25.4 15
Gasoline 0.63 2 B100 4.62 9 Glyphosphate 33.7 16
0.84 3 6.15 10 Atrazine 4L 44.8 17
Water/DEF 1.12 4 Jet Fuel 8.16 11 Propylene Glycol 59.5 18
1.48 5 10.8 12 10W-30 Oil/ATF 79.0 19
Mineral Spirits 1.98 6 14.4 13
NOTE: Use of the CAL/Fluid factor is independent from performing a calibration against a known volume. The meter is calibrated at the factory,
but performing a field calibration may further improve meter accuracy.
Fluid Calibration
Fluid calibration requires a container of a known volume at least 5 gallons or larger that is compatible with the fluid being metered. A larger volume
may be used and may improve calibration accuracy, but do not exceed 99.99 units of measure.
NOTE: Before performing a fluid calibration, ensure you have selected the closest matching CAL/fluid factor to ensure the best meter accuracy.
1. Press the 2 and 4 buttons at the same time and hold for three seconds. Display will show the firmware version.
2. Press button 3 to enter calibration mode. Unit of measure will be displayed.
3. Press button 3. The display will show “FILL”.
4. Dispense fluid into container. “FILL” will blink on the display when flow is detected.
5. After dispensing fluid, press the button. Left digit of the display will blink (“00.00”).
6. Press button 4 to increment digit to the amount of fluid dispensed (e.g.“05.00”). Press the button to move to right. Press button 2 to
start back at left-most digit if needed.
7. After number is loaded, press the button again to accept entered volume.
8. Display now shows the configured CAL factor.
9. Press the button again and the firmware version will be displayed.
10. Press the 2 button again to return to normal operating mode.
NOTE: If value entered is out of an acceptable range, display will read “Err0” and meter will revert to previous settings. See Table 2 on page 8 for the
Troubleshooting Guide.
If you are metering in ounces, pints, or quarts, it may be easier to switch the meter to a larger unit of measure such as gallons or liters for the
calibration process and then change back to the desired unit of measure.
