Fimar MCD/260E - Adjustment of Pressure Switch; Air Filter Cleaning (Only for Model MSD;400 - MSD;500)

▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬ PACKAGING MACHINE WITH SEALING BAR MSD
EN
346-062-3.fmIDM
- 14 - English language
AIR FILTER CLEANING (ONLY FOR MODEL MSD/400 - MSD/500)
1. Remove cup (N).
2. Extract and clean filter with a jet of
compressed air.
3. Install the filter and tighten cup (N).
ADJUSTMENT OF PRESSURE SWITCH
In case of suction problems during the
automatic operation of the equipment, adjust
screw (P) in order to regulate the suction time
of vacuum pump (Use supplied key "Torx
T30").
– Rotate clockwise in order to increase the
suction time of pump
– Rotate anti-clockwise in order to
decrease the suction time of pump
Important
The equipment is already regulated when it is
tested in factory. Carry out this operation only
in case of real need.
