Basic Specification
Remote controller
Net weight：About 331g
Screen resolution：480 x 272
Operating frequency：2.4-2.483GHz; 5.725-5.850GHz
Type：Rechargeable lithium battery
Capacity：2950mAh
Input：5V 2A
Memory card type：Micro SD（the maximum support32GB）
Operating temperature：0 ~ 40°C
Suitable altitude：≤5000m
Battery
Type：Rechargeable lithium battery
Weight：About 162g
Capacity：2000mAh
Voltage：11.1V
Limit voltage：12.75V
Energy：22.2Wh
Charging ambient temperature：0°C ~ 40°C
Gimbal
Controllable rotation range：0° ~ -90°（Pitch）
Control angle accuracy：± 0.02°
Lens：FOV80°
Camera aperture：f2.0
Camera focal distance：3.54mm
Equvalent focal distance：27mm
Sensor：1/3.2" CMOS
Effective pixels：8.08M
ISO range：100 - 3200（Video），100 - 1600（Photo）
Shutter speed：4 ~ 1/8000s
Max video resolution：1920 x 1080 | 30fps
1920 x 1080 | 25fps
Max photo resolution：3264×2448
File system：FAT32 / exFAT
Image format：JPG
Video format：MP4
Power adapter
Rated input：100-240V ~ 50/60Hz 0.3A
Rated output：14V 0.8A
Rated power：11.2W
Charging ambient temperature：0°C ~ 40°C
Remarks：
The 25 minutes flight time refer to the constant speed flight time when sigle battery cell voltage at 4.35v and with gentle breeze. Please use charger supported 4.35V.Remote control distance reach to 1km (FCC) in
open and no electro-magnetic interference area. All above testing and data are come from FIMI laboratory, errors may occur in actual use according to operating environmental changes.
Aircraft
Product model：FMWRJ01A3
Dimensions：285 x 229 x 69mm
Diagonal size：323mm
Takeoff weight：About 560g
Flight time：About 25min*
Max ascending speed：6m/s
Max descending speed：5m/s
Max cruising speed：18m/s
Max Transmission Distance：About 1000m*
Satellite positioning systems：GPS/GLONASS
Hover accuracy：± 0.5 m（Vertical），± 1.5 m（Horizontal）
Operating temperature：0 ~ 40°C
Suitable altitude：≤5000m
Memory card type：Micro SD ( Class10 above ) 8 ~ 64GB
Operating frequency：2.4-2.483GHz; 5.725-5.850GHz
Balance charge
Rated input：14V 0.8A
Rated output：11.1V 0.8A
