10
FEATURES
PRODUCT SPECIFICATIONS
Running Horsepower ................................................ 1.5 HP
Air Tank Capacity ........................................................ 3 gal.
Air Pressure ....................................................150 PSI max.
Air Delivery ......................................... 3.7 SCFM @ 40 PSI
............................................................ 2.8 SCFM @ 90 PSI
Lubrication .............................................................. Oil-Free
Gauges ....................................................... 1.5 in. diameter
Input.................................. 120 V, 60 Hz, AC only, 12 Amps
Net Weight (compressor only) ................................29.8 lbs.
Fig. 2
POWER
CORD
DRAIN
VALVE
SAFETY
VALVE
STORAGE
BOX FOR
ACCESSORIES
TANK
PRESSURE
GAUGE
REGULATOR
PRESSURE
GAUGE
PRESSURE
REGULATOR
KNOB
QUICK
COUPLER
HANDLE
MANUAL
ON/OFF
SWITCH
TANKS
BRAD NAILER
AIR CAULKING
GUN
AIR CHUCK
25’ PVC
HOSE
