Fini ROTAR PLUS 25 - Specifications

Rotar Plus 20-25 Easytronic - Cod.197AA2702 - Edition 00 01/2004
5
GB
SPECIFICATIONS
7HFKQLFDOIHDWXUHV
Pressure
EDU      
Compressor type
FS 50 TM FS 50 TM
Compressor rotation speed RPM
4830 4330 3460 5640 5200 4120
Air volume supplied l/min
2350 2050 1750 2700 2450 2050
Oil quantity l
777777
Oil quantity for topping-up l
0,5 0,5 0,5 0,5 0,5 0,5
Max. final over temperature °C
5561087
Removed heat kJ / h
51300 51300 51300 63270 63270 63270
Fan flow rate m³ / h
3100 3100 3100 2931 2931 2931
Oil residues in the air mg / m³
444444
Electric motor (bipolar)
160 L/2 B3 B5
Motor power kW
15 15 15 18,5 18,5 18,5
Max. power absorbed kW
18,4 18,4 18,4 21,5 21,5 21,5
Voltage V/Hz
Auxiliary voltage V/Hz
230-24 / 50-60 230-24/50-60
Electrical box protection class IP
54 54 54 54 54 54
Motor insulation class
FFFFFF
Full load current A
31 31 31 36 36 36
Starting load A
70 75 73 98 104 107
Max. Start-up per hour n°
10 10 10 10 10 10
Ambient limit temperature °C
50 50 50 50 50 50
Noise level at 1 m (Cagi pneurop) dB (A)
70 70 70 71 71 70
3URWHFWLRQGHY LFHV
Max compressor temperature °C
110 110 110 110 110 110
Min. oil temperature °C
-7 -7 -7 -7 -7 -7
Thermal motor cut-out A
19,8 19,8 19,8 23 23 23
Safety valve setting bar
14 14 14 14 14 14
Start-up pressure switch setting bar
1,5 1,5 1,5 1,5 1,5 1,5
'LPHQVLRQVDQGZHLJKW
Dimensions mm
Weight Kg
Air cock fitting Rp
3RZHUFRQQHFWLRQ
Power kW
15 15 15 18,5 18,5 18,5
Cable section (max. lenght 3 mt.) mm²
666666
Absorbed current A
31 31 31 36 36 36
Relay setting A
19,8 19,8 19,8 23 23 23
Switch A
50 50 50 63 63 63
+3 +3
132 MD/2 B3 B5
3/4" 3/4"
400 / 50 400/50
1030×680×1030 1030×680×1030
300 360
