7. Kusovník / Parts list
20
Position/Pozice Popis Description RozměryDimension Ks/Quantityy
3834--21 Karabiner Hook 3
-25 Kunststoffkappe Endcap 50x50x18.5 1
-32 Unterlegscheibe Washer Ø10.5xØ20xt 1.5 28
-33 Unterlegscheibe Washer Ø10.5xØ30xt 2.5 4
-34 Unterlegscheibe Washer Ø13xØ24xt 2.0 4
-39 Buchse Bushing Ø25.4xØ21.4xØ12x15 12
-51 Rolle Pulley Ø117xØ10x26 9
-52 Rollenabdeckung Pulley cover 10
-114 Mutter, selbstsichernd Safety nut M10 16
-122 Sechskantschraube Hexhead screw M10x55 1
-124 Sechskantschraube Hexhead screw M10x70 6
-127 Mutter, selbstsichernd Safety nut M12 2
-148 Sechskantschraube Hexhead screw M10x50 4
-149 Verbindungsrahmen Seilzugturm Connection tube 1
-150 Sechskantschraube Hexhead screw M10x150 1
-151 Sechskantschraube Hexhead screw M10x105 1
-152 Buchse Bushing Ø16x3 1
-153 Senkrechter Rahmen für Seilzugturm Vertical frame 1
-154 Sechskantschraube Hexhead screw M10x110 1
-155 Rollenhalter Pulley bracket 1
-156 Buchse Bushing 2
-157 Finnlo Knopf Finnlo knob 1
-158 Seilzugschlitten Slidder 1
-159 Handgriff Handles 2
-160* Seilzug Cable 7350mm 1
-161 Sechskantschraube Hexhead screw M12x170 2
-162 Dekorplatte, links Decoration cover, left side 2
-163 Doppelrollenhalter Double pulley bracket 2
- 164 Dekorplatte, rects Decoration cover, right side 2
*části označené hvězdičkou se častým užitím
opotřebovávají a je vhodné je kontrolovat, případně
kontaktujte zákaznický servis
The part numbers with an * are wear and tear parts, which
are subject to natural wear and which must be replaced after
intensive or long-term use. In this case, please contact Finnlo
Customer Service. You can request the parts and be charged
for them.

Finnlo Autark 2500 Specifications

General

Rowing	Yes
Product color	Anthracite, Black
Load weight step	5000 kg
Maximum load weight	80 kg
Maximum user weight	120 kg
Minimum load weight	5 kg

Weight and Dimensions

Depth	2150 mm
Width	2200 mm
Height	1650 mm
Weight	259600 g
