09
Schritt / Step 10
Position Bezeichnung Description: Teilenr.: Menge/
Part.No: Quantity
-9 Führungsrahmen, oben Top Beam Track 2
-10 Seitlich Strebe mit Rolle, oben Upper Mount, Cable Column 1
-11S Schraube Bolt 3/8-16 x 2 3/4“ L 2
-12S Schraube Bolt 3/8-16 x 3“ L 1
-23S Unterlegscheibe Washer 25 x 10 x 2T 6
-28S Mutter, selbstsichernd Locknut 3/8-16 UNC x 11T 3
