7.6 Fixing plastic sheet and insulation
After fixing the outside grating,insert the plastic sheet with insulation supplied with the conditioner
into the holes.The sheets must be 107mm shorter than the thickness of the wall.(See P18)
Use an ordinary cutter for the operation. (See P19)
Roll the sheet and insert it into the hole, paying attention to the splicing line, which must always
face up wards.(See P20)
7.7 Connecting drainage pipe
Connect the drain pipe(from rubber terminal) to the air conditioner (back side) after unplugged the
black rubber cu
p
(
see P21
)
.
p( )
With this solution, you can drain the condensate moisture to a suitable place to do not cause any
problems to your neighbours.
1. When the machine is installed in normal climate or hot area, we can connect the drainage pipe
to outside
, with a proper place. (See P22)
2. When the machine is installed in very cold area, the water in drainage pipe is frozen easily in
winter, we
could connect the drainage pipe inside the wall, and connect with a proper
place.(See P23)
7.8 Fitting the air conditioner on anchors
After checking again that the fastening anchors are securely fastened to the wall, and that any
necessary preparations for electric connection and condensate drainage have been made, fasten
the air conditioner to its supporting anchors.(See P24)
Lift it up by holding the sides at the bottom, slightly insert the outside fan rings into the two big
holes on the wall.
(
See P25
)
The air conditioner can now be
p
ushed firml
y
a
g
ainst the wall
,
then lift
() p yg
,
the unit and make sure the anchors and unit match well. (See P26)
Inspect carefully the installation to make sure that the insulating back panel must fit firmly against
the wall and there are no fissures at the back of the air conditioner.
Fixing two nuts with top of the machine, to make sure the unit is installed well. (See P27,28)
Note:
1. The appliance shall not be installed the laundry.
2. The appliance must be positioned so that the plug is accessible.
3. The appliance shall be installed in accordance with national wiring regulations.
7.9 Power cord connection
For every unit, there would be a power cord on the left side(P28).Connect the plug with the socket,
and operate the unit.
