Fintek iCOOL - Step Motor (Panel)

No. in Explosive
View
),17(. code BOM English Name Qty
iWARM Parts list
1 R128030549 PMMA 1
2 R128030543 Front panel 1
3 R128030554 Short pin 1
4 R128030552 Coupler 2
5 R128030548 Air filter 1
6 R128030553 Long pin 5
7 R131020097 LED display 1
8 R128030545 Front frame 1
9 R128030547 Step motor box 1
10 R128030550 Linkage 1
11 R128030551 Connectin
g
rod 1
g
12 R131060068 Step motor (panel) 1
13 R128030557 Flap1 1
14 R128030572 Flap2 1
15 R128030555 Outlet frame 1
16 R131060066 Step motor (plap) 2
17 R127041116 Right metal plate 1
18 R131040178 Indoor motor 1
19 R127020796 Evaporator motor support 1
20 R127020798 Indoor motor holder 2
21 R128060423 Bottom EPP 1
22
R128050021
Tangential fan
1
22
R128050021
Tangential
fan
1
23 R122010207 Evaporator assy. 1
24 R128060422 Upper EPP 1
25 R128060427 Front cover EPP 1
26 R127020823 Support plate 1
27 R140140071 Bottom metal assy. 1
28 R127020799 Compressor installation plate 1
29 R128060425 Water cover EPP 1
30 R128060426 Evaporator cover EPP 1
