iCOOL Parts list
No. in Explosive
View
),17(. code BOM English Name Qty
1 R133140024 Compressor and accessory 1
2 R122050360 Condenser assy. 1
3 R122060135 Capillary assy. 1
4 R122010207 Evaporator assy. 1
5 R122120281 4-way valve assy. 1
6 R131040178 Indoor motor 1
7 R131040175 Anticlockwise condenser fan 1
Cf
8 R131040176
C
lockwise condenser
f
an 1
9
R131060068 Step motor (panel) 1
10 R131060066 Step motor (plap) 1
11 R131010509 Main PCB 1
12 R131160054 Compressor capacitor 1
13 R127030254 Compressor capitor holder
14
R131030006
3
way terminal block
1
14
R131030006
3
-
way
terminal
block
1
15 128060209 Wire protection ring 1
16 R131130003 Condenser fan capacitor 2
17 R139010035 Power plug protection ring 1
18 R132040139 Power plug 1
19 R128030549 PMMA 1
20
R128030543
Front panel
1
20
R128030543
Front
panel
1
21 R128030545 Front frame 1
22 R128030555 Outlet frame 1
23 R128030557 Flap1 1
24 R128030572 Flap2 1
25 R138140752 Insulation material for flap1 1
26 R128030547 Ste
p
motor box 1
p
27 R128030550 Linkage 1
28
R128030551 Connecting rod 1
29 R128030552 Coupler 1
30 R128030554 Short pin 2
31 R128030553 Long pin 5
32 R128030548 Air filter 1
33 R128030561 Outside grille 1
34 R128030286 Axis sleeve 2
35 R128050021 Tangential fan 1
36 R139050004 Axletree seat 1
37 R128060423 Bottom EPP 1
