FIORENTINI I42TD - Water Discharge; Recovery Tank Drainage

TECHNICAL DATA
I42TD – I60TD
Rev. 00
January 2005
17/36
Water discharge.
The scrubber is equipped with one pipe for the water discharge (picture no. 9):
 Recovery tank water discharge (detail 1 picture 9)
If you need to discharge water from the tanks, you have to place the machine on a dump well, release the
pipe of the tank and open the rubber cap at the end of the pipe itself.
1
Figura 6
Picture no.
9
