INSTRUCTIONS
CUCCIOLO
Rev. 000
January 2005
31/36
Remove the sponge filter under the motor, wash it and put it again in its position (see detail 3 in
picture no. 19);;
Check the motor fan through the hole in the front side of the suction motor;
Remove the plastic cover, loosen the screws and both coal brushes supports and check the motor
coal brushes (see picture no. 21);
Do now the opposite operations to set everything up again.
1
2
3
