FIORENTINI S32B - Technical Specifications

TECHNICAL DATA
S32B
Revision 00 Maggio 2006 Page 10 di 37
2.3
TECHNICAL DATA
FEATURES
LENGTH x WIDTH x HEIGHT
1815 x 1010 x 1400 mm
N° BRUSHES
1 CENTRAL + 1 o 2 SIDE
TRACTION
HYDRAULIC
CENTRAL BRUSH DIMENSION
Ø330 x 800mm
SIDE BRUSHES DIMENSION
Ø500 mm
SWEEPING WIDTH
1050 mm
SWEEPING WIDTH WITH LEFT SIDE BRUSH
1300 mm
WHEEL DIAMETER
400 - 6 mm
FILTERING SURFACE
6 m²
WASTE TANK
180 litri
WEIGHT WITHOUT BATTERIES
535 Kg
ENGINE
BRUSHES HYDRAULIC ENGINE
TRACTION HYDRAULIC ENGINE
VARIABLE DELIVERY PUMP
FIXED DELIVERY PUMP
VACUUM MOTORS
FUNCTIONS
DRIVE
MAN ON BOARD
U-TURN LANE
CENTRAL BRUSH LIFTING UP SYSTEM
MANUAL
SIDE BRUSH LIFTING UP SYSTEM
HYDRAULIC
SERVICE BRAKE
MECHANICAL
PARKING BRAKE
MECHANICAL WITH A LEVER
PERFORMANCES
FORWARD SPEED
0 – 6 Km/h
REVERSE SPEED
0 – 6 Km/h
MAX SLOPE
10%
MAX SLOPE FOR U-TURN
5% a 3 Km/h
WORKING CAPACITY UP TO m² /h
8450 m²/h
ECOLOGICAL FEATURES
NOISE AT OPERATOR’S EAR
< 80 DECIBEL
VIBRATIONS AT OPERATOR’S SEAT
< 2.5 m/s²
