FIORENTINI S32B - Machine Movement and Braking

TECHNICAL DATA
S32B
Revision 00 Maggio 2006 Page 14 di 37
Moving the machine.
By means of the forward/reverse pedal the operator can move the machine. The operator has to put the foot
onto the pedal and press it with the heel to move forward or with the top of the foot to move the machine
backward.
Stopping the machine.
The sweeper is equipeed with one parking brake and one service brake. The last one (see picture 5) is controlled by a
pedal placed next to the forward/reverse pedal. The parking brake is controlled by a knob (see picture 7). The operator
Forward speed
Reverse speed
4
Forward/reverse
p
eda
l
5
Service brak
e
