Side brush replacement
¾ Unscrew the bolts (picture 13) and remove the brush;
¾ replace the brush and tighten the bolts again.
How to replace the vacuum filter of the sweeping group and filter shaker engine
¾ Important: remove the key from the dashboard of the sweeper;
¾ open the bonnet of the machine by means of the button (picture 14);
¾ lift the waste tank cover up;
¾
unloose both screws that hold the filter (picture 15);
¾
remove the filter shaker support;
¾
disconnect the connectors of the shaker filter engine;
¾
lift up and replace the damaged or clogged filter;
¾
follow now the opposite operations.
