Fire-Lite 411UDAC - 411 UDAC Backbox

Mounting
20
411UDAC Document #51073 Rev. D 12/09/2008 P/N 51073:D
Top
Bottom
Right Side
Door=12.714“ (32.294 cm)
Backbox=12.5“ (31.75 cm)
Door=14.714“ (37.374 cm)
Backbox=14.5“ (36.83 cm)
Depth=2.875“ (7.303 cm)
Depth=3“
(7.62 cm)
FIGURE 2-3:411UDAC Backbox
411ACABB.CDR
