FCPS-24FS Series Instruction Manual — P/N 51883:H1 4/14/2011 11
Specifications System Overview
Control Input Circuits - TB4, Terminals 3 (+) & 4 (-) and 7 (+) & 8 (-)
• Trigger Input Voltage: 9 to 32 VDC
• Input Current Draw in Alarm Polarity:
– 16 to 32 volts, 2.0 mA maximum per input
– 9 to 16 volts, 1.0 mA maximum per input
NAC/Output Circuits - TB2, Terminals 1 (+) & 2 (-), 3 (+) & 4 (-), 5 (+) & 6 (-) and
7 (+) & 8 (-) alarm polarity
• Supervised, Special Application and power-limited
• Voltage Rating: 24 VDC filtered
• Current:
– Maximum for any one circuit - 3.0 amps
– Maximum total continuous
current for all output:
FCPS-24FS6 - 4.0 amps
FCPS-24FS8 - 6.0 amps
– Maximum total short term
current (one hour maximum) for all outputs:
FCPS-24FS6 - 6.0 amps
FCPS-24FS8 - 8.0 amps
• Output Circuit Types:
– Four Style Y NACs (require 4.7 KEnd-of-Line Resistors) or
Style Z NACs using the optional ZNAC-4 Class A converter module
OR
– Four resettable or nonresettable 24 VDC power outputs
• Refer to the Fire•Lite Device Compatibility Document #15384 for listed compatible devices.
• For wiring requirements, refer to “Wire Requirements” on page 43.
Trouble Relay Contact Rating - TB5
• Fail-safe Form-C relay (normally energized, transfers with loss of power)
• 5.0 amps @ 24 VDC or 5.0 amps @ 30 VAC
Secondary Power (battery) Charging Circuit - JP4
• Supervised, nonpower-limited
• Supports lead acid type batteries only
• Float Charge Voltage: 27.6 VDC
• Maximum Charge Current: 1.5 A
• Battery fuse (F1) 15A, 32V (Canadian version is nonreplaceable 12A, 32V)
• Maximum Battery Capacity: 18.0 AH
• Minimum Battery Capacity: 7.0 AH
• Power supply draws maximum standby current of 65 mA from batteries
Auxiliary Special Application Power Output - TB4 Terminals 9 (+) & 10 (-)
• Special application power
• Power-limited, nonsupervised
• Voltage Rating: 24 VDC
• Current:
– 170 mA maximum with internal 7.0 Amp Hour batteries
