8.2 SLIMLINE SILVERPAC - PARTS
17 4
2
1
10
7
8 9
5
1112
3
6
14
16
15
13
18
19
20
21
No. Qty Description 18-20 kW 20-26 kW
1 - Tube baffle BA112379 BA112379
2 4 Smoke baffle BA212028 BA212028
3 1 Door seal ACC035GRA ACC035GRA
4 1 Door duroboard ACC035GSK ACC035GSK
5 1 Flue gasket ACC000FRG ACC000FRG
6 1 Stat pocket ACC003PKT ACC003PKT
7 1 Condensate trap ACC000TRP ACC000TRP
8 1 Condensate hose ACC000FLX ACC000FLX
9 1 Drain cock ACC012DRC ACC012DRC
10 1 Heat deflector ACC000HDF ACC000HDF
11 1 Flap valve adapter ACC000FVA ACC000FVA
12 1 Flap valve ACC000FLP ACC000FLP
13 1 Flue kit HPF035SLM HPF035SLM
14 1 Control panel ACP001SPS ACP001SPS
15 1 Casing right side ACP002SPS ACP002SPS
16 1 Casing left side ACP003SPS ACP003SPS
17 1 Casing front ACP004SPS ACP004SPS
18 1 Casing top ACP005SPS ACP005SPS
19 1 Casing back ACP006SPS ACP006SPS
20 1 Casing flue outlet ACP106SPS ACP106SPS
21 1 Terminal guard ACC000CTG ACC000CTG
For burner parts refer to Burner manual
