8
25
8.4 - SILVER UTILITY - PARTS
3
4
2 1 10
7
158 9
6
5
1112
14
16
13
17
18
No. Qty Description
15-20 kW 20-26 kW 26-35 kW
1 Tube baffle 112379 112379 110908
2 4 Smoke baffle 212022 212028 212122
3 1 Door seal 111314 111314 111314
4 1 Door duroboard 110918 110918 110918
5 1 Flue gasket 112104 112104 112104
6 1 Stat pocket 111317 111317 111317
7 1 Condensate trap 112184 112184 112184
8 1 Condensate hose 111537 111537 111537
9 1 Drain cock 111329 111329 111329
10 1 Heat deflector 210904 210904 210904
11 1 Air hose 111902 111902 111902
12 1 Flap valve 114192 114192 114192
13 1 Casing back support 212322 212322 212322
14 1 Control panel 310952 310952 310952
15 1 Casing right side 211878 211878 211878
16 1 Casing left side 211879 211879 211879
17 1 Casing top 211876 211876 211876
18 1 Casing front 211875 211875 211875
For burner parts refer to Burner manual
