8
24
8.3 - SILVER BOILERHOUSE - PARTS
4 3 2 10
7
8
9
6
5
15
16
14
12
17
11
13
1
For burner parts refer to Burner manual
No. Qty Description
15-20 kW 20-26 kW 26-35 kW
1
-
Tube baffle 112379 112379 110908
2 4 Smoke baffle 212022 212028 212122
3 1 Door seal 111314 111314 111314
4 1 Door duroboard 110918 110918 110918
5 1 Flue gasket 112104 112104 112104
6 1 Stat pocket 111317 111317 111317
7 1 Condensate trap 112184 112184 112184
8 1 Condensate hose 111537 111537 111537
9 1 Drain cock 111329 111329 111329
10 1 Heat deflector 210904 210904 210904
11 1 Air hose 111902 111902 111902
12 1 Flap valve 114192 114192 114192
13 1 Dual thermostat 111316 111316 111316
14 1 Casing right side 212179 212179 212179
15 1 Casing left side 212182 212182 212182
16 1 Casing back 212180 212180 212180
17 1 Casing burner panel 212181 212181 212181
