Installation:
• Turn the alarm body counterclockwise and take off the
bracket.
• Press the bracket on the installation position, mark
installation hole of the bracket with pencil.
• Drill two installation holes with electric drill. Make diameter
of holes 5mm. Strike the two plastic plugs into holes with
hammer.
• Attach the bracket to the plastic plugs and x the screws
tightly into the plastic plugs. (refer to Diagram 7).
• Connect the battery to power connector.
• Fix the battery into battery box.
• Fit the alarm on the bracket and turn the alarm body
clockwise until matching well on the bracket.
• Test smoke alarm using test button. The alarm will sound 3
short beeps – 1.5 seconds pause, then repeat it until release
the button.
Diagram 4
- 5 -
