8
3. Attach the Table Top (C) to the Legs using Stud(8*30mm)(J),
Washer, Spring Washer, & Nut(8mm)(K). Tighten with
Wrench(R). Place the Burner (B) into the Table Top (C).
NOTE: Make sure the Control Knob on the Burner is
aligned with the Door so you can access the Control
Knob.
Hardware Used
4. Pour the Fire Glass (V) around the Burner. Be careful not to
obstruct pilot light housing. Place the Burner Cover (A) on the Burner
when the fire pit is NOT in use. When the fire pit is completely cool,
you may cover it with the Protective Fire Pit Cover (T). DO NOT PUT
THE PROTECTIVE FIRE PIT COVER ON A HOT FIREPIT.
