QUICK USER GUIDE FOR 1-8 ZONE FIRE PANELS
USER CODE BUTTON ACTION
3545
LEVEL 2a
1 – RESET
Return the system to a normal condition after a fire or fault
has occurred. This should only be performed when the fire
or fault has been identified and alarms have been silenced.
2– SILENCE
BUZZER
Stops the sounding of the internal buzzer.
3 – SILENCE /
SOUND ALARMS
Turn off the fire alarm sounders whilst the system is being
cleared after a fire. Sound the fire alarms to evacuate the
building. Other devices will not be triggered
4,5 – WALK TEST Tests detectors and callpoints on a zone. The sounders will
sound for 1 second then reset.
Zones tested are indicated on the panel
5 – LAMP TEST -
EXIT
Lights all LEDs and beeps the internal buzzer for 2 seconds.
Then exits from Level 2a function
5344
LEVEL 2b
1 – RESET
Return the system to a normal condition after a fire or fault
has occurred. This should only be performed when the fire
or fault has been identified and alarms have been silenced.
2– SILENCE
BUZZER
Stops the sounding of the internal buzzer.
3,4 – DISABLE /
ENABLE ZONE
Disable zones & alarms if a fault occurs – does not affect
the other zones. Select as follows:-
3 - Selects/deselects the zone/alarm
4 - Moves flashing light to the required zone.
5 – EXIT
Exit from Level 2b function.
INDICATORS COLOUR INDICATION
FAULT /TEST
/DISABLE –
COMMON
Yellow On when a fault condition has occurred, or if no other fault
Led is on, this indicates 24v auxiliary fuse has tripped.
FIRE - COMMON
Red On when a FIRE condition has occurred.
ZONES 1-8
FAULT
Yellow Flashes if a detector is removed from its base, or an
open/short circuit zone wiring fault.
On when a zone is disabled and flashed when in walk test.
ZONES 1-8 FIRE
Red On during a FIRE condition in this zone.
Flashed when a device has been tested during walk test.
SUPPLY
Green On while power is being supplied to the panel.
SUPPLY FAULT
Yellow Flashes during a mains or battery supply failure.
DISABLED
Yellow Zones and / or alarm are disabled. The specific zone or
alarm fault led will also be lit.
ALARM FAULT/
DISABLED
Yellow Flashes with a fault on the sounder wiring.
Illuminated if alarm lines are disabled.
ALARM
SILENCED
Yellow Sounders on the alarm circuits during a fire/evacuation
condition have been switched off.
TEST
Yellow Walk test function selected.
EARTH FAULT
Yellow Will illuminate if a fault occurs with the earthing.
SYSTEM FAULT
Yellow Illuminated if the panel has “crashed” and an attempt to
restart the system has been made. Flashed if an error in the
system software has been detected – Requires attention.
DELAY ENABLED
Yellow Alarms are delayed if switch is activated.
