H08053 PARTS LIST
NO.
Part Number
Description
Qty.
NO.
Part Number
Description
Qty.
1
357713572
FIRMAN 439cc Dual Fuel Engine
1
74
357713552
Battery
1
2
357713501
Rubber Cap B
1
75
357713553
Battery Holder
1
3
336713528
Flange Bolt M6×8
5
76
357713554
Flange. Bolt M8×45
2
4
357713573
Generator Wind Shield
1
77
336713593
Screw&washer Assy M5×10
2
5
380713535
Rotor Assy
1
78
357713569
Nut M5
3
6
380713536
Stator Assy
1
79
336713578
Bolt, Bend Hook
2
7
380713537
Stator Cover
1
80
357713555
Battery Red Cable +
1
81
357713556
Black Boot
1
8
357713506
Generator End Cover
1
82
336713693
Battery cable(Female 180mm)
1
9
357713507
Carbon Brush Assembly
1
83
357713557
Nut M10
2
10
336713525
Carbon Brush Holder
1
84
357713531
Isolator 2
1
11
336713524
Bolt &washer Assemblies
1
85
357713532
Isolator 1
1
12
380713504
AVR
1
86
357713533
Motor Mount
2
13
336713519
Flange Bolt M5×16
2
87
357713585
Flange. Bolt M8×16
4
14
336713523
Terminal Block
1
88
336713559
Support Leg
1
15
336713520
Bolt M5×16
2
89
357713538
Rubber, Support
2
16
336713522
Ground Wire
1
90
336713557
Flange Bolt M6×25
4
17
357713509
Generator End Cover Cap
1
91
336713561
Ground Wire
1
18
336713507
Flange Bolt M5×12
3
92
336713514
External Star Washer Ø6
1
19
380713506
Flange Bolt M6×200
4
93
336713516
Receptacle L14-30R
1
20
336713512
Lock Washer Ø6
8
94
336713601
Control Module
1
21
336713513
Washer Ø6
4
95
336713817
Circuit Breaker Amp 33A
2
96
380713516
Tapping Screw St2.9×19
2
22
336713577
Nut M5
2
97
336713819
Tapping Screw St2.9×32
1
23
380713507
Side Cover Bolt M5×229
2
98
336713820
Micro Switch 1
1
24
357713511
Lock Washer Ø5
2
99
336713821
Micro Switch 2
2
25
380713508
Flange Bolt M10×285
1
100
336713822
Fuel Valve
1
26
357713513
Lock Washer Ø10
1
101
336713824
Main Regulator Assy.
1
27
357713514
Washer Ø10
5
102
336713823
LPG Inlet Cover
1
28
336713531
Flange Bolt M8×20
4
103
336713826
Screw M4×12
1
29
357713515
Holder, Muff
1
104
336713816
Fuel Selector Switch
1
30
336713515
Flange Bolt M6×12
19
105
336713815
Electric Start Switch
1
31
357713516
Muffler Fixed Plate A
1
106
336713827
Indicator Light
1
32
336713538
Screw&washer Assy M5×14
2
107
336713828
Multi Meter
1
33
357713517
Holder, Spark Arrester
1
108
357713586
Outlet Cover TT-30R
1
34
336713536
Arrester, Spark
1
109
336713574
Outlet Cover L5-30R
2
35
357713518
Muffler Fixed Plate B
1
110
336713573
Outlet Cover 5-20R GFCI
1
111
357713541
Bolt M6×22
1
36
336713534
Nut M8
2
112
380713512
Nut M6
2
37
336713509
Lock Washer Ø8
2
113
380713515
Tapping Screw St4.8×20
2
38
336713533
Flat Washer Ø8
2
114
336713830
Screw&washer Assy M4×8
10
39
357713520
Gskt., Ext.
1
115
336713569
Screw&washer Assy M3×6
4
40
380713538
Muff.,Assy.
1
116
330713582
Screw&washer Assy M4×14
6
41
357713523
Muffler Fixed Plate C
1
117
380713539
Control Panel
1
42
336713517
Nut M6
4
118
380713518
Receptacle 14-50R
1
43
357713577
Air Filter Bracket
1
119
336713568
Nut M4
8
44
357713524
Rubber Cap A
1
120
357713588
5-20R Duplex GFCI
1
45
336713542
Grommet, Fuel Tank
4
121
336713586
Circuit Breaker Amp 30A
1
46
336713543
Washer Tank Buffer
4
122
336713585
Circuit Breaker Amp 20A
1
47
336713544
Flange Bolt M6×20
4
123
336713565
Screw M5×14
4
48
357713578
Fuel Gauge Assy.
1
124
336713818
Charger
1
49
336713546
Screw M5×10
2
125
336713583
Receptacle L5-30R
1
126
357713590
Control Box
1
50
336713547
Fuel Gauge Display
1
127
357713545
Grommet
1
