Menus (continued)
Camera Display Menu:
Options to change settings and
adjust the camera view can be
accessed by either right-clicking
or left-clicking on the camera
display. The functions of the two
menus are explained at right.
Device Network Menu:
Options to change settings for the
device network connections can
be adjusted by right-clicking on
the device name in the LAN/WAN
display. The functions of the menu
is explained at right.
• Right Click Menu
(on camera video)
• Left Click Menu
PROGRAM FUNCTIONS
MENUS
1. Return: Close the menu.
2. Listen: Turn on camera microphone.
Click again to turn off.
3. Talk: Turn on camera speaker.
Click again to turn off.
4. +/-: used for camera zoom.
5. PTZ Directional Control: Click to
pan or tilt the camera.
6. Capture: Take a photo.
7. (Begin) Record: Start video/audio
recording.
8. More: Select to adjust camera settings.
9. Close: Close the Camera display.
10. Motion Detection Area: Adjust the
area of view for motion detection.
11. Full Screen: Enlarge camera display
to fill whole monitor screen.
1 3 5 7
2
4
6
8
5
7
8
10
9
11
1
3
6
2
7
9
8
1. H264/MPEG4 Player: Stream via
H264/MPEG4.
2. Sub-stream Player: Stream via
sub-stream protocol.
3. Close H264/MPEG4 / Close
Sub-stream: Turn off feed.
4. Add Device: Click to add an
additional camera.
5. Create a Group: To create
camera groups, more than one
camera required.
6. Change Access Password:
Select to change the access
password. If 5 digit password was
used on initial Remove setup.
Adding the 4 digit access password
will allow Remove viewing.
7. Change the Device Alias: Select
to Remove your camera (i.e. front
door, kitchen).
8. Micro-SD Card Query: Select
to manage micro-SD card files and
directories.
9. Remove Device: Remove device
from list.
