z When mounting on the wall, it can be installed only
vertically (FIGURE 2a), not horizontally (FIGURE
2b).
VERTICAL HORIZONTAL
FIGURE 2a & 2b
z The distance between floodlight and PIR motion
sensor cannot be too close because the heat from
the floodlight will hinder the normal operation of the
PIR motion sensor. (FIGURE 3)
FIGURE 3
z Both camera and PIR can be adjusted
counter-clockwise and clockwise. The camera is
30° and PIR is 90° to each side.
(FIGURE 4)
FIGURE 4
z The suggested swiveling angle of camera and PIR
are outlined hereunder: (FIGURE 5)
Wall mount
Ceiling mount
FIGURE 5
IMPORTANT
Skilled technicians who are informed about the
standards and technical requirements of the
appliance and its proper installation must perform
installation.
A qualified electrician or technician shall do
maintenance or repairing work such as replacing
current fuse.
Before proceeding with the installation, TURN OFF
THE POWER TO THE LIGHTING CIRCUIT AT THE
CIRCUIT BREAKER OR FUSE BOX TO AVOID
ELECTRICAL SHOCK.
CHOOSING A MOUNTING LOCATION
z For best results, install your PIR LIGHTING
CAMERA on a solid surface, 6.5ft. above the
ground.
z For outdoor installation, a location under eaves is
preferable.
z Avoid aiming the motion sensor at pools, heating
vents, air conditioners or objects that may change
temperature rapidly.
z Do not allow sunlight to hit directly on the front of
the unit.
z Try to avoid pointing the unit at trees or shrubs
where the motion of pets or animals may be
detected.
z The transmission range to the Wireless Receiver is
up to 300ft. in clear line of sight. *Quality of picture
will deteriorate as the distance increases.
z Prior to mounting the light fixture, remember to
position the motion sensor so that a moving object
