FISCHBEIN F Series - Page 76

FISCHBEIN
®
F SERIES PORTABLE SEWING MACHINES
OPERATOR’S MANUAL
REV. H 9/2011
76
MODEL MODEL F HORIZONTAL STITCHER ASSEMBLY
Plate "K"
ITEM
QUAN.
PART NO.
DESCRIPTION
2 1 A2455 Assembly, Bracket
3 1 A2457 Weldment, Bracket Mounting
4 1 A2458 Bracket, Mounting
5 2 WS14 Washer, Spring 1/4
6 4 SF14201 Screw, Soc Flat 1/4-20 x 1 BO
7 4 NJ1420 Nut, Hex Jam 1/4-20 UNC
8 1 SF83258 Screw, Soc Flat #8-32 x 5/8
10 1 A1845 Lever, Microswitch
11 2 SS103238 Screw, Soc Set #10-32 x 3/8 BO
12 1 A4366 Block, Lever - Microswitch
13 1 P2587 Switch, Actuator
14 1 P3476 Cordgrip, 1/2 NPT - 0.312-0.375
15 1 10-80 Cordset
16 1 A2589 Assembly, Safety Pin - Stitcher
17 2 SC1032112 Screw, Soc Cap #10-32 x 1 1/2 BO
18 2 WL10 Washer, Lock #10
19 1 10-41 Rod, Threaded Clamping
20 1 A2568 Weldment, Base-Mntg
21 1 11805 Nut, Wing-Washer Base - 1/4-20
22 2 WL14 Washer, Lock 1/4
