DIMENSIONS
Models
DishDrawer® Std
Double
DishDrawer® Std
Single
DD24DCX6
DD24DCW6
DD24DCB6
DD24DDFX6 DD24DI6
DD24SCX6
DD24SCW6
DD24SCB6
DD24SDFX6 DD24SI6
PRODUCT DIMENSIONS
Overall height* of product
819.5-879.5
819.5-879.5 819.5-879.5 409 409 409
Overall width of product 595 595 595 595 595 595
Overall depth of product (excl.
curvature/handle)
570 570 570 570 570 570
Depth of drawer (open) (excl.
curvature/handle)
520 520 520 520 520 520
Height* of chassis 809 809 809 409 409 409
Height range of levelling feet 60 60 60 - - -
Depth of chassis
552 552 552 552 552 552
Depth of drawer front panel
(excl. curvature/handle)
18 18 18 18 18 18
Depth of curvature or handle 11 41 n/a 11 41 n/a
Depth of toekick 50-110 50-110 67- 127**** - - -
Height of upper drawer front 394 398 398 min - - -
Height of lower drawer front 351 356 311.5 min - - -
Height of toekick (adjustable) 70- 120 70- 120 70- 120 - - -
Height of venting area at base
of product
- - - 7 9 9
Height of installation bracket
slots (on top of chassis)
2 2 2 2 2 2
Height of drawer fronts 751 764 717.5 394 398 398 min
Height* of top of upper drawer
to top of chassis
7 2 n/a 7 2 n/a
CABINETRY DIMENSIONS
Inside height of cavity 820-882.5 820-882.5 820-882.5 412 412 412
Inside width of cavity 600 600 600 600 600 600
Inside depth of cavity (inside) 580 580 580 580 580 580
Height of adjacent cabinetry 762 762 720 - - -
Height of toekick 70- 120 70- 120 70- 120 - - -
Clearance below benchtop** Min. 3 Min. 3 Min. 3
* Chassis height include bracket slots
** Clearance is measured from the underside of benchtop to the chassis
*** Panel thickness- 18mm
**** Prefinished 50-65mm; Integrated 67mm less the Toekick Panel thickness (minimum Panel thickness using the supplied screws is 9).
.
Product Code: FPDD605
www.spaequip.com P: 707-737-1100 F: 707-737-1150 Page 8 of 18
