Fisher Labs CZ-3D - Table of Contents

CONTENTS
About Your Detector ................................................................ pg. 3
Condensed Operating Instructions ........................................ pg. 4
Factory Preset “Turn-On-And-Go” Marks .............................. pg. 4
Setting Up .................................................................................. pg. 5
Hipmounting.............................................................................. pg. 7
Control Panel ............................................................................ pg. 7
Turn-On Procedure ................................................................... pg. 9
Ground Balancing .................................................................... pg. 9
Pushbutton Method .................................................................. pg. 10
“Bobbing” The Search Coil Method ....................................... pg. 10
Search Modes ........................................................................... pg. 12
Search Modes: Auto Tune ....................................................... pg. 13
Search Modes: Target ID ......................................................... pg. 13
Searching ..................................................................................pg. 18
Pinpointing: Pushbutton Pinpoint Mode .................................. pg. 20
Pinpointing: Target ID and Autotune Modes .......................... pg. 21
Depth Reading .......................................................................... pg. 24
Target Recovery ....................................................................... pg. 25
Recovery Tools .......................................................................... pg. 26
False Signals .............................................................................. pg. 26
Maintenance ............................................................................ pg. 27
Treasure Hunters’ Code Of Ethics ............................................ pg. 28
Battery Replacement ............................................................... pg. 29
Specications ........................................................................... pg. 30
NOTES:
1. Subject to improvement or modication without notice.
2. Approximate.
3. The CZ-3D disassembles to t into an optional carrying case measuring
approximately 6" x 21" x 15".
4. The CZ-3D Fourier Domain Signal Analysis transmits multiple frequencies
simultaneously and processes two received frequencies for deeper
target ID in mineralized soil.
5. VCO: Voltage Controlled Oscillator. Volume and frequency increase as
target is approached for pinpoint accuracy.
6. The CZ-3D is a motion detector in the AUTOTUNE and Target ID modes. The
search coil must be moving at least slightly to detect a target.
7. For maximum performance and battery life, always use Alkaline Batteries.
8. Compensates for salt water and sand minerals simultaneously.
9. Volume control limits loud-target response, amplies faint targets when
level is set above 5.
10. ESI: Electro-Static Insulated to eliminate certain types of false signals.
SPECIFICATIONS
SEARCH COIL ...................................................................................................
Type ........................................ Concentric, Co-planar Spider Coil
Diameter ................................ 8"
Shielding ................................. 100% ESI
10
Interchangeable .................. Yes
Submersible ............................ Yes
WARRANTY ................................2-Year Limited Warranty*
*Warranty may vary outside of the United States, see your dealer for details
OPTIONAL ITEMS ............................................................................................................
Coil covers, hard carrying case, 10 1/2" Spider coil, 5" search coil, carry
bag, holster, Fisher phones, stereo phones
