18
Edit Controls (cont.)
Image EQ
You can program unique EQ settings for each of the Images. Unlike other Edit
parameters, unique tone settings are automatically saved with each Image and
recalled when an Image is selected. In order to prevent dramatic or unwanted
changes, the Image EQ’s Treble, Mid, and Bass controls are separated from the
Pickup EQ and located “under” the Volume knob in Edit. They are identifi ed by
a lowercase t, m, b, corresponding to Treble, Mid, and Bass respectively.
To EQ an Image:
1. Adjust the Blend control so that you are hearing 100% Image (page 12)
2. Press Edit knob to enter Edit and select an Image
3. Press the Volume button to select the Image Treble EQ (t)
4. Turn the Edit knob to boost or cut the Image Treble EQ
5. Repeat steps 3 & 4 to adjust the Image Mid (m) and Image Bass (b)
