Phase Invert Control with Push-Pull Potentiometer
Quick Reference - 3 Ways to Configure Potentiometer Rotary Function
.15uF
Solder
0.15uF
Capacitor
“154”
Tone
Reactor
Volume
Standard
Tone
Reactive
Tone
Apply Solder to
Connect Pads
for Volume
Function
