“224”
.22uF
25k
Phase Invert Control with Push-Pull Potentiometer
Basic Wiring Example - Phase Invert as Volume Control
Neck
Volume IN
Volume OUT
Bridge
Neck Pickup
Bridge Pickup
Both
Output
Jack
9V Battery
Ring
Tip
Sleeve
(-)
(+)
Tone
Volume,
Pull for
Neck Pickup
Phase Invert
Neck Pickup Output
to Phase Inverter
Bridge Pickup Output
Neck +9-18V
Pickup
Voice-2
Wires
Pull for
Voice-2
Invert
Trim
Toggle Switch Style
Pickup Selector
Bridge +9-18V
Apply Solder to
Connect Pads
for Volume
Function
