Fishman Loudbox 100 Owner's Manual

Owner's Manual
Techical Specifications Cont'd
Channel 1 & 2 D.I. Out
Output Impedance 600 Ohm balanced
Phantom power tolerant, ground isolated
Channel 1 & 2 Effects Sends:
Output Impedance 2.2k Ohm
Output Voltage +3dBV (1.4Vrms max)
-10dBV Nominal
Channel 1 & 2 Effects Returns:
Input Impedance 20k Ohm
Input Voltage +3dBV (1.4Vrms max)
-10dBV Nominal
Sends and returns are compatible with battery operated effects processors
Mix D.I. Out:
Output Impedance 600 Ohm balanced
Phantom power tolerant, ground isolated
Tuner Out:
Output Impedance 5k Ohm
Speaker System:
Woofer 8” paper cone
Tweeter 1” soft dome, rare earth magnet, ferrofluid cooled
Tweeter Level Up to 6dB cut
Crossover 4kHz (Bi-amplified with active crossover)
Baffle Angle 10 Degrees
Physical:
Dimensions 16” x 13.5” x 11.5” (40.5cm x 34cm x 29cm)
Weight 23 lbs (10.5 kg)
We reserve the right to change any of the the specifications and information in this manual without notice.
15

Fishman Loudbox 100 Specifications

General

Brand	Fishman
Model	Loudbox 100
Category	Musical Instrument Amplifier
Language	English
