SPECIFICATIONS
Nominal Input Level: -20 dBV
Input Overload: (20 Hz - 20 kHz)-2 dBV
Input Impedance: 20 M Ohms
Output Impedance: Less than 3.5 k Ohms
Nominal Output Level: -12 dBV
THD: Less than .04 %, -20 dBV input
Signal to Noise Ratio: 77 dB
(A weighted referred to nominal
-20 dBV input)
Current Drain: Less than 3.5 mA
Power Supply: 9V Alkaline battery
(estimated 160 hours continuous use with low
battery indicator at 6.5V)
Notch Filter Range: 40Hz - 500 Hz (-15 dB)
Bass Control Range: ± 12 dB at 60 Hz
± 3 dB at 350 Hz
Treble Control Range: ± 12 dB at 10 kHz
± 3 dB at 2.4 kHz
Contour Control Range: ± 12dB
(adjustable from 250 Hz to 10 kHz) Q = 0.5
Brilliance Control Range: ± 9 dB at 10 kHz
± 3 dB Bandwidth 7 kHz
All specifications subject to change without notice.
ONBOARD ACOUSTIC GUITAR SYSTEM
11
