For more detailed instructions please visit www.fishman.com/tripleplay
TriplePlay Hardware Installation Quick Start (continued)
Mounting the controller using the end-pin bracket:
1
2
Loosen your guitar's end-pin, then attach
the selected End-Pin Bracket by sliding the
bracket's slotted tab onto the guitar's
end-pin screw. Lower the bracket onto the face of
your guitar, and re-tighten the end-pin.
Test-fit the Magnetic Ring Mount
to the End-Pin Bracket with the
adhesive backing facing down.
3
When ready, remove the adhesive backing
and attach the Magnetic Ring Mount to the
End-Pin Bracket. Press firmly for 30 seconds
along the entire length of the Magnetic Ring Mount
to ensure a good bond to the End-Pin Bracket.
