Exploded Drawing and Parts List
(Picture N)
Part No. Description Num-
ber
Dimensions
1 Bicycle frame 1
2 Foot with castors, front 1
3 Foot, rear 1
4 Flat-head screw
(Spare part no.: 49871000030)
4 M8 x 62 mm
5 Washer, curved
(Spare part no.: 49871000030)
8M8
6 Cap nut (Spare part no.: 49871000030) 4 M8 x 62 mm
7 Right pedal (Spare part no.: 49871000020) 1
8 Left pedal (Spare part no.: 49871000020) 1
9 Saddle holder 1
10 Adjusting screw (height of the seat) 1
11 Saddle (Spare part no.: 49871000040) 1
12 Washer, straight
(Spare part no.: 49871000030)
5M8
13 Nut (Spare part no.: 49871000030) 5 M8 x 62 mm
14 Holder for back pad 1
15 Flat-head screw
(Spare part no.: 49871000030)
2 M8 x 45 mm
16 Side handlebar
(Spare part no.: 49871000060)
1
17 Hexagon socket screw
(Spare part no.: 49871000030)
2 M8 x 35 mm
18 Back pad
(Spare part no.: 49871000050)
1
19 Hexagon socket screw
(Spare part no.: 49871000030)
6 M8 x 40 mm
20 Handlebar
(Spare part no.: 49871000060)
1
21 Spring washer
(Spare part no.: 49871000030)
2M8
22 Training computer
(Spare part no.: 49871000010)
1
23 Cross-head screw
(Spare part no.: 49871000030)
2 M5 x 10 mm
24 Locking screw 1
