4
Assembling Flash
How to assemble the bike
3. Assemble the handlebar on the stem using a provided
4mm allen key. Remove the (4x) 4mm screws from the
stem. Then attached the handlebar as shown in the
image. Then angle the brakes on the handlebar at 45
degrees towards the front of the bike. Then tighten the
4x 4mm screws on the stem at 7Nm - 8Nm of torque.
We have provided YouTube videos at http://support.flashbike.io with detailed
instructions on how to assemble your bike. Written instructions are below.
2. Assemble the front wheel on the bike’s front fork.
1. Start first by attaching the skewer to the front hub and
wheel.
To Next Page
