TYPE 1 - WIRE CROSS REFERENCE CHART
MAKE MODEL YEAR WIRE DESCRIPTION
CONNECTOR
POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR NAME COLOR TYPE
MAZDA
CX-5
PTS
AT
13
12V 0940-103B White 24 pin 12 Yellow (+) Start stop unit, under the steering column B
Brake 0940-103A White 32 pin 02 Red/Blue (+) Start stop unit, under the steering column B
Ignition 0940-103A White 32 pin 17 Violet (+) Start stop unit, under the steering column B
PTS 0940-103A White 32 pin 20 Green/White (-) Start stop unit, under the steering column B
RX 0940-103A White 32 pin 16 White (DATA) Start stop unit, under the steering column B
CanH 0940-103B White 24 pin 07 White/Black (DATA) Start stop unit, under the steering column B
CanL 0940-103B White 24 pin 08 Red/Yellow (DATA) Start stop unit, under the steering column B
Doorlock ~ ~ ~ ~ White/Green (DATA) Driver side running board C
Parking Light 1 ~ White 06 pin 03 Yellow (-) Parking light switch D
Parking Light 2 ~ White 06 pin 04 Green (-) Parking light switch D
