TYPE 1 - WIRE CHART - 1 OF 1
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
CHRYSLER
300/300C 05-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/DkGreen (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
PT Cruiser 06-10
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/LtBlue (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Brown/Tan (-) Switch ~
DODGE
Caliber
(with start wire)
07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/DkGreen (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple/Blue (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ ~ ~ ~ ~
Charger 06-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/DkGreen (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
Magnum 05-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/DkGreen (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
JEEP
Commander 06-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/Orange (+) Ignition switch ~
Parking Light* ~ ~ ~ 85 ~ (-) Parking light relay, engine compartment. ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
Grand Cherokee 05-07
Control C1 Black 5 pin 2 Violet/Brown (MUX) Ignition switch ~
Starter C1 Black 5 pin 4 Pink/Orange (+) Ignition switch ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple/Blue (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
* Requires additional parts.
