FlashLogic FLRSCH5 - Page 9

TYPE 2 - WIRE CHART - 3 OF 3
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
JEEP
Patriot 07-13
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light* ~ ~ ~ ~ White/Purple (+) Driver kick panel ~
Driver Door Pin ~ ~ ~ ~ Purple/Blue (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ ~ ~ ~ ~
Wrangler 07-13
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light* ~ ~ ~ ~ White/Purple + White/Orange (+) Passenger kick pad ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
RAM
4500 10
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light ~ ~ ~ ~ White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
5500 10
Mux ~ ~ ~ ~ ~ ~ ~ ~
Starter ~ ~ ~ ~ ~ ~ ~ ~
Parking Light ~ ~ ~ ~ White/Green (MUX) Switch ~
Driver Door Pin ~ ~ ~ ~ Purple (-) Driver kick panel ~
Hood Status ~ ~ ~ ~ Purple/LtBlue (-) Switch ~
* Requires additional parts.
